150/115/80 Watt; 30K/40K/50K CCT; Field Selectable LED; Corncob; Mogul Extended Base; 120-277 Ranged (X6VKP)

Image may not reflect selected features

No Image
Available

150/115/80 Watt; 30K/40K/50K CCT; Field Selectable LED; Corncob; Mogul Extended Base; 120-277 Ranged

BASE PRICE:

165

/ / 1

($165.90 / 1)

WAS

Call for Price

Item #:

X6VKP

Dimensions:

Width: 4.10"

Finish Family:

White

Availability:

Manufacturer has 264 items available.

Description

Details

Downloads

150/115/80 Watt; 30K/40K/50K CCT; Field Selectable LED; Corncob; Mogul Extended Base; 120-277 Ranged Voltage; 450 Watt HID Replacement

Category:

Light Bulbs

Subcategory:

LED Bulbs

Category:

LED

Sub-Category:

HID Replacements

Volts:

120V-277V

Bulb Dimmable:

Yes-Dimmable

Bulb Hours:

50000

Bulb Kelvin:

3000K/4000K/5000K

Bulb Shape:

Corncob

Diameter:

4.1

EA Length:

4.33

Harmonized Codes:

8539.52.0091

Length:

8.300000000000001

Lumens:

24812L/19816L/14270L

Shap Carton Width:

4.33

Ship Carton Height:

10.04

Ship Weight:

1.94

Warranty:

5 Year Limited - High Lumen Hi-Pro

Weight:

1.72

Ballast Bypass Direct:

Ballast Bypass

Ballasting Requirements:

Ballast Bypass

Beam Spread:

207

Bulb ANSI Base:

EX39

Bulb Base:

Mogul Extended

Bulb Finish:

White

Burning Position:

Universal

Carton Cubic Feet:

0.1089

Cartons Per Unit:

CCT Selectable:

Yes

CEC:

Exempt - Base Not Regulated

CEC Terse:

Lawful for sale in California

CEC Web Text:

Lawful for sale

Color Temprature:

Soft White to Natural Light

Country Of Origin:

China

CRI:

80+

Dimmable Function:

Only dimmable through wattage selection switch on lamp

Dimming Type:

Step Dimming

DLC Approved:

Yes

DLC Classification:

Standard

DLC ID:

S-5PHZP8

DLC Primary Use:

Replacement Lamps for High-Bay Luminaires (Type B)

Efficacy:

165.41/172.31/178.38 LPW

Enclosed Fixture Use:

Yes

FCC Compliant:

Yes

Feature 1:

CCT and Wattage Selectable

Feature 10:

5 Year Warranty

Feature 2:

Range Voltage 120V-277V

Feature 3:

Very High Lumen Output

Feature 4:

Type B Ballast Bypass

Feature 5:

Integrated Active Cooling Fan

Feature 6:

Damp location rated

Feature 7:

Min Compartment Size 18.50" x 12.60" x 12.60"

Feature 8:

6kV Surge Protection

Feature 9:

50,000 Hour Functional Life

HID Equivalent:

450W

Housing Color:

White

Indoor Outdoor:

Indoor and Outdoor

Installation Notes:

Not for use in vapor tight fixtures.

IP Rating:

IP54

JA8 Compliant:

Lamp Ballast Type A/B/C:

Type B

Lamp Filament:

LED

Lens Finish:

Clear

Lens Material:

Polycarbonate (PC)

Location Rating:

Damp

Long Description:

SATCO NUVO's S23134 Hi-Lumen Hi-Pro lamp delivers over 24,000 lumens, replacing metal halide lamps up to 450W with energy-efficient LED performance. Field-selectable wattage and CCT provide versatility, while the extended mogul EX39 base and enclosed f

Material:

Aluminum / Polycarbonate (PC)

Minimum Compartment Size:

Length: 18.50 in. Width:12.60 in. Height: 12.60 in.

Operating Frequency:

60Hz

Operating Temp:

-40C (-40F) to +50C (+122F)

Order In Multiples Of:

Pack Type:

Box

Power Factor:

0.99

Quantity In Pack:

R9 Value:

RoHS Compliant:

Yes

Romance Copy:

SATCO NUVO Hi-Lumen Hi-Pro lamps deliver exceptional LED illumination, replacing metal halide lamps from 450W up to 1000W. With a staggering maximum output of over 73,000 lumens, they provide superior brightness while improving energy efficiency and reduci

SDS class:

LED_Lamp

Short Description:

150W/LED/CCT/100-277V/EX39

Style:

Contemporary

Surge Protection:

Built-in surge protection - 6KV

Technology:

LED

Title 20 Compliant:

Exempt

Title 24 Compliant:

Total Harmonic Distortion:

<20%

Wattage Selectable:

Yes

Watts:

150W/115W/80W
