LED Shoe Box Lamp; 90/100/110 Wattage Selectable; 3K/4K/5K CCT Selectable; 120-277 Volt; White (X6PNT)
$190.00
Call For Price
Enlarge Image
Add to Cart
Description:
LED Shoe Box Lamp; 90/100/110 Wattage Selectable; 3K/4K/5K CCT Selectable; 120-277 Volt; White Finish
Availability:
  • Manufacturer has 1374 items available.
Required Components:

Optional Accessory:

Dimensions:
right arrow Width: 8.90"
Additional Details:
right arrow Finish Family: White
right arrow Category: LED
right arrow Sub-Category: HID Replacements
right arrow Volts: 120V-277V
right arrow Bulb Dimmable: Yes-Dimmable
right arrow Bulb Hours: 50000
right arrow Bulb Kelvin: 3000K/4000K/5000K
right arrow Bulb Shape: Integrated LED
right arrow Diameter: 8.9
right arrow EA Length: 12.68
right arrow Harmonized Codes: 8539.52.0091
right arrow Length: 11.26
right arrow Lumens: 13500L/14500L/15400L
right arrow Shap Carton Width: 5.71
right arrow Ship Carton Height: 6.46
right arrow Ship Weight: 4.67
right arrow Warranty: 5 Year Limited - Hi-Pro
right arrow Weight: 3.68
right arrow BAA Compliant: No
right arrow Ballast Bypass Direct: Ballast Bypass
right arrow Ballasting Requirements: Ballast Bypass; Direct wire 120-277V line voltage; No ballast or external driver required
right arrow Beam Spread: 180
right arrow Bulb ANSI Base: EX39
right arrow Bulb Base: Mogul Extended
right arrow Bulb Finish: White
right arrow Burning Position: Universal
right arrow Carton Cubic Feet: 0.2707
right arrow Cartons Per Unit: 1
right arrow CCT Selectable: Yes
right arrow CEC: Exempt - Base Not Regulated
right arrow CEC Terse: Lawful for sale in California
right arrow CEC Web Text: Lawful for sale
right arrow Color Temprature: Soft White to Natural Light
right arrow Country Of Origin: China
right arrow CRI: 80+
right arrow Dimmable Function: Only dimmable through wattage selection switch on lamp
right arrow Dimming Type: Step Dimming
right arrow DLC Approved: Yes
right arrow DLC Classification: Standard
right arrow DLC ID: S-7KJXW6
right arrow DLC Primary Use: Replacement Lamps for Outdoor Pole/Arm-Mounted Area and Roadway Luminaires (Type B)
right arrow Efficacy: 150.00/145.00/140.00 LPW
right arrow Enclosed Fixture Use: Yes
right arrow FCC Compliant: Yes
right arrow Feature 1: CCT and Wattage Selectable
right arrow Feature 2: Expandable Light Panels
right arrow Feature 3: 320 Degree Rotating EX39 Base
right arrow Feature 4: Integrated 4kV Surge Protection
right arrow Feature 5: Advanced Heat Dissipation
right arrow Feature 6: Type B Ballast Bypass
right arrow Feature 7: 5 Year Warranty
right arrow HID Equivalent: 250W/320W/400W
right arrow Housing Color: White
right arrow Incandescent Equivalent: 750W
right arrow Indoor Outdoor: Outdoor
right arrow Installation Notes: Not for use in vapor tight fixtures.
right arrow IOT Enabled: No
right arrow JA8 Compliant: No
right arrow Lamp Ballast Type A/B/C: Type B
right arrow Lamp Filament: LED
right arrow Lens Material: Polycarbonate (PC)
right arrow Location Rating: Damp
right arrow Long Description: SATCO NUVO's S28938R1 LED Hi-Pro Lamp offers a 320 degree rotating EX39 base making the installation of this lamp easier than ever. The two different on-unit CCT and Wattage Selectable switches give the user the power to customize the lighting for each
right arrow Material: Aluminum
right arrow Minimum Compartment Size: Length: 11 in. Width: 11 in. Height: 11.6 in.
right arrow Operating Frequency: 50/60Hz
right arrow Operating Temp: -30C (-22F) to +45C (+113F)
right arrow Order In Multiples Of: 1
right arrow Pack Type: Box
right arrow Power Factor: >0.9
right arrow Quantity In Pack: 1
right arrow RoHS Compliant: Yes
right arrow Romance Copy: SATCO NUVO's LED Hi-Pro Lamps offer a 320 degree rotating EX39 base making the installation of these lamps easier than ever. The two different on-unit CCT and Wattage Selectable switches give the user the power to customize the lighting for each unique
right arrow SDS class: LED_Lamp
right arrow Short Description: 110W/LED/HID/SB/3CCT/EX39
right arrow Style: Utility
right arrow Surge Protection: Built-in surge protection - 4KV
right arrow Technology: LED
right arrow Title 20 Compliant: Exempt
right arrow Title 24 Compliant: No
right arrow Total Harmonic Distortion: <20%
right arrow Wattage Selectable: Yes
right arrow Watts: 90W/100W/110W
right arrow Standard Category: Light Bulbs
right arrow Standard Subcategory: LED Bulbs
right arrow Standard Finish: White
